Short S10/CT Slip Ring Assembly



Features

  • 10 slip ring connections
  • Cable clamp and eyelet
  • Color-coded solder terminals on rotor and stator
  • Instrumentation quality rings and brushes
  • Sealed, corrosion resistant metal housing
  • Lightweight and compact

Description

The Short S-Series models are available in four to ten circuit slip ring assemblies. Connections are made through color-coded solder terminals on the rotor and stator. The stator includes a cable clamp and eyelet. The lightweight and compact design of these slip ring assemblies make them ideal for use in applications where limited space is available.

For applications that also require signal amplification, the Short S-Series slip ring assembly can be used with Michigan Scientific’s thermocouple or strain gauge amplifiers. For applications with extremely limited space, Michigan Scientific can manufacture the slip ring assembly to have an amplifier integrated directly into the rotor, not changing the dimensions of the slip ring.

Documents

Last Modified: May 9, 2022 @ 9:55 am
